Product intended for professional use onlyModels
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAB7640Modbus TCP Slave - CANopen SlaveOut of stock Warranty: €701.00€862.23Login to check your price AB7640Modbus TCP Slave - CANopen SlaveAvailability: Out of stockNet price:€701.00
Technical Specification
- Specyfikacja techniczna
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 24 VDC (?10%) |
| Temperature: | 0-65°C |
| Current Consump: | max 300 mA |
| I/O Input: | Default 20 bytes, max 512 bytes |
| I/O Output: | Default 20 bytes, max 512 bytes |
| Mech Rating: | IP20/Nema1 |
| Config Method: | Windows Hyper Terminal |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connector: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| Modbus-TCP connector: | RJ45 |
| Modbus-TCP address: | Any valid IP-address |
| CANopen baudrate: | 10 kbit/s to 1 Mbit/s |
| CANopen connector: | D-sub 9-pin male |
| CANopen address: | Node address 1-99 |
| CANopen config.: | Configured by CanOpen Master via EDS file (provided by HMS) |
| Modbus-TCP baudrate: | 10/100 Mbit/s autodetect |
| Price Group: | A |
| Order Code: | AB7640 |
Download
