ABC3013-A Modbus RTU Master - PROFINET Device
Price from €640.00 Net price
If placed an order by 3 p.m., the package will be shipped the same day In stock
Price from €701.00 Net price
High price? Log in and buy cheaper
Product out of stock
Free shipping from €300
Promocja cenowa na model HDR-15-5
Product intended for professional use onlyModels
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAB7661Profinet IO Slave - CC Link SlaveOut of stock Warranty: €701.00€862.23Login to check your price AB7661Profinet IO Slave - CC Link SlaveAvailability: Out of stockNet price:€701.00
Technical Specification
- Specyfikacja techniczna
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 24 VDC (?10%) |
| Temperature: | 0-65°C |
| Current Consump: | max 300 mA |
| I/O Input: | Default 20 bytes, max 64 bytes (max 128 I/O-points and 16 words on CC-Link) |
| I/O Output: | Default 20 bytes, max 64 bytes (max 128 I/O-points and 16 words on CC-Link) |
| Mech Rating: | IP20/Nema1 |
| Config Method: | Windows Hyper Terminal, GSD-file for Profinet |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connect: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| CC-Link baudrate: | 156kbps to 10Mbps |
| CC-Link address: | Station 1-64 |
| CC-Link connector: | 5-pole 5.08 mm Phoenix pluggable screw connector |
| CC-Link config: | Configured by CC Link Master via CSP Config file (provided by HMS) |
| Profinet connector: | RJ45 |
| Profinet IP-address: | Any valid IP-address |
| Profinet baudrate: | 100Mbit/s |
| Price Group: | A |
| Order Code: | AB7661 |
