AB7817
AB7817 Devicenet Master Modbus Rtu Slave
Price from €1,336.00 Net price
High price? Log in and buy cheaper
Product out of stock
Free shipping from €300
Promocja cenowa na model HDR-15-5
Product intended for professional use onlyModels
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAB7817DeviceNet Master - Modbus RTU SlaveOut of stock Warranty: €1,336.00€1,643.28Login to check your price AB7817DeviceNet Master - Modbus RTU SlaveAvailability: Out of stockNet price:€1,336.00
Technical Specification
- Specyfikacja techniczna
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 24 VDC (?10%) |
| Temperature: | 0-65°C |
| Current Consump: | max 300 mA |
| I/O Input: | Default 20 bytes, max 512 bytes |
| I/O Output: | Default 20 bytes, max 512 bytes |
| Mech Rating: | IP20/Nema1 |
| Config Method: | Windows Hyper Terminal |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connector: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| DeviceNet baudrate: | 125-500 kbit/s |
| DeviceNet MacID: | 0-63 |
| DeviceNet connector: | 5-pole 5.08 mm Phoenix pluggable screw connector |
| Modbus RTU baudrate: | 1200 Bit/s to 57 600 Bit/s |
| Modbus RTU address: | Node address 1-247 |
| Modbus RTU connector: | D-sub 9-pin female |
| Accessory order: | 018021 (NetTool-DN configuration tool for DeviceNet) |
| Price group: | B |
| Order Code: | AB7817 |
Download
