Promocja cenowa na model HDR-15-5
Product intended for professional use onlyModels
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAB7868CANopen Slave - ControlNet SlaveOut of stock Warranty: €1,460.00€1,795.80Login to check your price AB7868CANopen Slave - ControlNet SlaveAvailability: Out of stockNet price:€1,460.00
Technical Specification
- Specyfikacja techniczna
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 24 VDC (?10%) |
| Temperature: | 0-65°C |
| Current Consump: | max 300 mA |
| I/O Input: | Default 20 bytes, max 512 bytes (max 450 bytes as I/O on ControlNet) |
| I/O Output: | Default 20 bytes, max 512 bytes (max 450 bytes as I/O on ControlNet) |
| Mech Rating: | IP20/Nema1 |
| Config Method: | Windows Hyper Terminal |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connector: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| ControlNet baudrate: | 5Mbit/s |
| ControlNet MacID: | 1-99 |
| ControlNet connector: | Dual BNC coaxial connectors |
| ControlNet config.: | Configured by ControlNet Scanner via EDS file (provided by HMS) |
| CANopen baudrate: | 10 kbit/s to 1 Mbit/s |
| CANopen connector: | D-sub 9-pin male |
| CANopen address: | Node address 1-99 |
| CANopen config.: | Configured by CanOpen Master via EDS file (provided by HMS) |
| Price Group: | C |
| Order Code: | AB7868 |
Download
