Manufacturer: Clock Computer Corporation
Price from €396.00 Net price
High price? Log in and buy cheaper
In stock
Place the order by 12:00, the package will be shipped on the same day
Free shipping from €300
Promocja cenowa na model HDR-15-5
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddLA-2132-K512LA-2132-K512Out of stock Warranty: €396.00€487.08Login to check your price LA-2132-K512LA-2132-K512Availability: Out of stockNet price:€396.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddLA-2132-M512LA-2132-M512Out of stock Warranty: €527.00€648.21Login to check your price LA-2132-M512LA-2132-M512Availability: Out of stockNet price:€527.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddLA-2132-G512LA-2132-G512Out of stock Warranty: €659.00€810.57Login to check your price LA-2132-G512LA-2132-G512Availability: Out of stockNet price:€659.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddLA-2132 LVDS-G512LA-2132 LVDS-G512In stockWarranty: €659.00€810.57Login to check your price LA-2132 LVDS-G512LA-2132 LVDS-G512Availability:In stockNet price:€659.00
Description
Technical Specification
- Częstotliwość próbkowania, pamięć
| Seria LA-2132 K | 32 kanały: od 1Sa/s do 250 MSa/s; pamięć 256 K |
| Seria LA-2132 M | 32 kanały: od 1Sa/s do 250 MSa/s; pamięć 512 K 16 kanałów: od 1Sa/s do 500 MSa/s; pamięć 1 M |
| Seria LA-2132 G | 32 kanały: od 1Sa/s do 250 MSa/s; pamięć 1 M 16 kanałów: od 1Sa/s do 500 MSa/s; pamięć 2 M 8 kanałów: od 1Sa/s do 1 GSa/s; pamięć 4 M |
- Parametry analizatora
| Częstotliwość zewnętrznego zegara | do 125MSa/s |
| Pasmo | DC - 125MHz |
| Impedancja wejściowa | 250Kohm // 2pf (Tip to ground) |
| Napięcie wejściowe | Max. -110 V do +110 V |
- Kanały cyfrowe
| Napięcie progowe | -3.7V do 1.9V z krokiem 35mV ECL(-1.3V) LVC 1.5V (0.75V) LVC 1.8V (0.9V) LVC 2.5V (1.2V) LVC 3.3V (1.4V) SSTL2 II 2.5V (1.25V),br /> SSTL3 II 3.3V (1.4V) |
| Channel Skew | Typical < 200ps |
| Trigger position | Any position for user defined |
| Max. Trigger Speed | 250MHz (4ns) |
| Trigger Quality | 0, 1, x (don't care) settings for all Digital channels 2, 8, 512 Trigger Levels |
- Parametry techniczne
| Zasilanie | z portu USB |
| Waga netto | 120 g |
| Wymiary | 105mm x 73mm x 17mm |
