GigaEter Duo 19 5GHz WideBand

Broad-band double polarizated antenna with gain of 19 dBi

Manufacturer: Cyberbajt

broad-band double polarizated antenn
Frequency range: 4,9 - 6,0 GHz
Gain: 19 dBi
Connector: 2xN/Female
MIMO 2x2

Price from €50.00 Net price

High price? Log in and buy cheaper

In stock

Place the order by 12:00, the package will be shipped on the same day

Free shipping from €300

See 1 model

Promocja cenowa na model HDR-15-5

Models
Description
Technical Specification

GigaEter Duo 19 5GHz WideBand

Models

Model	Availability	Warranty	Wishlist	Your Price	Your Price	Items Quantity Add
GigaEter Duo 19 5GHz WideBand (3200) directional 5 GHz MIMO 19 dBi	In stock	Warranty:		€50.00 €61.50 Login to check your price	Login to check your price	pcs.

GigaEter Duo 19 5GHz WideBand (3200)

directional 5 GHz MIMO 19 dBi

Availability:

In stock

Net price:

€50.00

Description

PAN 5-19HV WB is broad-band double polarizated antenna with gain of 19 dBi, it's predicted for operation at the frequency of 4900 - 6000 MHz. Antenna is designed for
dual links and 2x2 MIMO links at the standard of 802.11n on medium distances.

Separation between connectors is 37dB. This antenna distinquish itself with wide beamwidth, from 4900 MHz up to 6000MHz. Medium antenna gain allows for realize wireless links on
medium distances. Narrow radiation beam allows to avoid interferences and noise level even on short distances.

Antenna has DC ground what prevents devices connected with antennas.

Solid bracket and U-Bolt come with antenna, they ensure for stability and resistance for wind and allows for antenna slope (advantage with making precise links).

Technical Specification

Antenna type	directional
Frequency range	4,9 - 6,0 GHz
Gain for vertical polarization	19 dBi (min) 5,25-5,875 GHz 17.5dBi (min) 4,9-5,25 GHz; 5,875 - 6,0 GHz dBi
Gain for horizontal polarization	19 dBi (min) 5,25 - 5,875 GHz 17.5dBi (min) 4,9 - 5,25 GHz; 5,875 - 6,0 GHz dBi
Polarization	vertical + horizontal
Back ratio	(max) -30 dB
Separation between connectors	> 37 dB
Vertical beam width	18 ° for -3dB
Horizontal beam width	18 ° for -3dB
VSWR	1,5:1 (typ) 1,9 : 1 (max)
Impedance	50 Ohm
Connector	2 x N/Female
Maksymalna moc	6 W
Wind load	56 m/s
The diameter of the mast / pole	38 - 51 mm
Dimensions	390 x 430 mm
Package dimension	49/41/9 cm
Total weight	1654 g
Weight with mounting	1250 g
Weight without mounting	850 g
Warranty	36 months
