ICR-2834-S1
Secure LTE Industrial Router (IEC 62443-4-2 SL1 Compliant)
- Support for LTE Cat. 4, HSPA+, UMTS, GPRS/EDGE technologies
- Security based on IEC 62443-4-2 level 1
- Dual SIM card slots
- 2× 10/100 Mbps Ethernet ports
- 2× serial ports RS-232/RS-485 (configurable via DIP switches)
- Built-in 4× digital inputs (DI) and 2× digital outputs (DO)
- USB 2.0 Host port
- GNSS support (GPS, GLONASS, BeiDou, Galileo)
- External antenna connectivity
- Operating temperature range: –40 to +75 °C
- VPN tunneling support (IPsec, OpenVPN, L2TP)
- Support for DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, SMS control, and many other features
- Durable metal housing, IP20-rated
- Power supply input range: 9–36 V DC
High price? Log in and buy cheaper
Free shipping from €300
Promocja cenowa na model HDR-15-5
Product intended for professional use only
ICR-2834-S1
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddICR-2834GA01-S1Cellular Router, Cat4, Accessories EUOut of stock Warranty: €504.00€619.92Login to check your price ICR-2834GA01-S1Cellular Router, Cat4, Accessories EUAvailability: Out of stockNet price:€504.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddICR-2834WA01-S1Cellular Router, Cat4, WIFI, Accessories EUOut of stock Warranty: €737.00€906.51Login to check your price ICR-2834WA01-S1Cellular Router, Cat4, WIFI, Accessories EUAvailability: Out of stockNet price:€737.00
Accessories
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddLTE antennaIn stockWarranty: €7.00€8.61Login to check your price LTE antennaAvailability:In stockNet price:€7.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddLTE antennaIn stockWarranty: €6.00€7.38Login to check your price LTE antennaAvailability:In stockNet price:€6.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddDIN rail power supply 15W 24V 0.63AIn stockWarranty: €11.00€13.53Login to check your price DIN rail power supply 15W 24V 0.63AAvailability:In stockNet price:€11.00
Description
The ICR-2834-S1 is an industrial-grade LTE Category 4 cellular router designed for applications that demand a high level of cybersecurity. Based on the proven ICR-2834 platform, it offers similar network and interface capabilities. However, the S1 variant has been specifically adapted to meet the requirements of the IEC 62443-4-2 Security Level 1 standard.
The router incorporates a comprehensive set of security features in line with the standard, including secure boot, a read-only file system with integrity checks (AIDE), encrypted firmware images, enforced strong password policies, account lockout mechanisms, restricted administrative access (no root account), and the use of only strong cryptographic algorithms (e.g., SHA-256, RSA-3072, ED25519). The web interface is HTTPS-only, and extensibility is limited to secure, signed Router Apps in the .raw format.
The device supports LTE Category 4 cellular communication with automatic fallback to 3G or 2G when LTE is unavailable. It is equipped with two independent 10/100 Mbps Ethernet ports, two SIM slots with failover support, two RS-232/RS-485 serial ports selectable via DIP switches, a USB 2.0 host port, and four digital inputs and two digital outputs. Optional Wi-Fi (802.11ac/a/b/g/n) is also available.
The router runs on the ICR-OS S1 Linux-based operating system and includes 1.3 GB of eMMC storage for applications and data. It supports a wide range of advanced networking features such as DHCP, NAT, VRRP, VLAN, SNMP, NTP, DynDNS, firewall, and DMZ, as well as VPN tunneling via OpenVPN, WireGuard, IPsec, and GRE. Protocol conversion for Modbus RTU/TCP, DNP3, MQTT, IEC 101/104, and others is supported through approved Router Apps only.
S1 routers cannot be created from standard models — they must be factory-produced as S1 devices. They require the dedicated ICR-OS S1 firmware and compatible .raw format applications. The user interface is visually identical to standard routers but marked with “S1” and an orange accent color in the GUI.
Advantech also provides a cloud-based management platform, WebAccess/DMP, which enables:
- Remote device diagnostics
- Centralized fleet management
- Cloud-based configuration, including automated provisioning when the device is first powered on
- Simple, encrypted VPN creation
- Grouping of devices into communication domains
- Defining communication rules (e.g., which subnets can interact)
