Manufacturer: MEAN WELL
- Compliance to EN50155 and EN45545-2 railway standard
- 2:1 wide input range
- Protections: Short circuit / Overload / Over voltage / Over temperature / Input reverse polarity
- 4000VDC l/O isolation
- Cooling by free air convection
- Half encapsulated
- Built-in constant current limiting circuit
- 1U low profile 40mm
- All using 105°C long life electrolytic capacitors
- LED indicator for power on
- 100% full load burn-in test
Price from €66.80 Net price
High price? Log in and buy cheaper
In stock
Place the order by 12:00, the package will be shipped on the same day
Free shipping from €300
Promocja cenowa na model HDR-15-5
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100B-5DC/DC converter 100W 14.4~33.6V-5V 20AIn stockWarranty: €66.80€82.16Login to check your price RSD-100B-5DC/DC converter 100W 14.4~33.6V-5V 20AAvailability:In stockNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100B-12DC/DC converter 100W 14.4~33.6V-12V 8.4AIn delivery Warranty: €66.80€82.16Login to check your price RSD-100B-12DC/DC converter 100W 14.4~33.6V-12V 8.4AAvailability: In deliveryNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100B-24DC/DC converter 100W 14.4~33.6V-24V 4.2AIn delivery Warranty: €66.80€82.16Login to check your price RSD-100B-24DC/DC converter 100W 14.4~33.6V-24V 4.2AAvailability: In deliveryNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100C-5DC/DC converter 100W 28.8~67.2V-5V 20AOut of stock Warranty: €66.80€82.16Login to check your price RSD-100C-5DC/DC converter 100W 28.8~67.2V-5V 20AAvailability: Out of stockNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100C-12DC/DC converter 100W 28.8~67.2V-12V 8.4AIn stockWarranty: €66.80€82.16Login to check your price RSD-100C-12DC/DC converter 100W 28.8~67.2V-12V 8.4AAvailability:In stockNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100C-24DC/DC converter 100W 28.8~67.2V-24V 4.2AIn stockWarranty: €66.80€82.16Login to check your price RSD-100C-24DC/DC converter 100W 28.8~67.2V-24V 4.2AAvailability:In stockNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100D-5DC/DC converter 100W 57.6~154V-5V 20AOut of stock Warranty: €66.80€82.16Login to check your price RSD-100D-5DC/DC converter 100W 57.6~154V-5V 20AAvailability: Out of stockNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100D-12DC/DC converter 100W 57.6~154V-12V 8.4AIn stockWarranty: €66.80€82.16Login to check your price RSD-100D-12DC/DC converter 100W 57.6~154V-12V 8.4AAvailability:In stockNet price:€66.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddRSD-100D-24DC/DC converter 100W 57.6~154V-24V 4.2AIn delivery Warranty: €66.80€82.16Login to check your price RSD-100D-24DC/DC converter 100W 57.6~154V-24V 4.2AAvailability: In deliveryNet price:€66.80
Description
RSD series of single-output converters is designed for use in the railway industry (trams, trains, etc.). A wide range of input voltages and various output voltage configurations ensure high flexibility of applications. High quality, reliability, durability and long service life are the basic advantages of MEAN WELL inverters.
Technical Specification
-
RSD-100: 100W~100.8W DETAILS
Model Input Output Ripple & noise Efficiency Dimension RSD-100B-5 16.8~31.2V 5V, 0~20A 100mV 88% 161x68x36mm RSD-100B-12 16.8~31.2V 12V, 0~8.4A 120mV 89% 161x68x36mm RSD-100B-24 16.8~31.2V 24V, 0~4.2A 150mV 89% 161x68x36mm RSD-100C-5 33.6~62.4V 5V, 0~20A 100mV 89% 161x68x36mm RSD-100C-12 33.6~62.4V 12V, 0~8.4A 120mV 91% 161x68x36mm RSD-100C-24 33.6~62.4V 24V, 0~4.2A 150mV 91% 161x68x36mm RSD-100D-5 67.2~143V 5V, 0~20A 100mV 89.5% 161x68x36mm RSD-100D-12 67.2~143V 12V, 0~8.4A 120mV 91% 161x68x36mm RSD-100D-24 67.2~143V 24V, 0~4.2A 150mV 90% 161x68x36mm
