- wide range of supply voltage VAC and VDC
- built-in active PFC chip
- low power consumption in no-load condition <1W
- 2 charging stages (constant current, constant voltage)
- two-color LED indicating the operating status
- high reliability
- short-circuit, overload, overvoltage and thermal protection
- fully enclosed plastic housing
- 1st class of insulation
- AC input: IEC320-C14
- cooling with open air circulation
- wide operating temperature range (-30 - + 60OC)
- efficiency up to 94%
- compliance with a number of standards and certificates
- 2 years warranty
High price? Log in and buy cheaper
Free shipping from €300
Promocja cenowa na model HDR-15-5
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGC330A36-C4Pdesktop battery charger 330W 40.8V 8AOut of stock Warranty: €78.20€96.19Login to check your price GC330A36-C4Pdesktop battery charger 330W 40.8V 8AAvailability: Out of stockNet price:€78.20 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGC330A48-C4Pdesktop battery charger 330W 54.4V 6AOut of stock Warranty: €78.20€96.19Login to check your price GC330A48-C4Pdesktop battery charger 330W 54.4V 6AAvailability: Out of stockNet price:€78.20
Accessories
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity Add2-pin EU plug with FG + IEC320-C13 INLETIn stockWarranty: €4.00€4.92Login to check your price 2-pin EU plug with FG + IEC320-C13 INLETAvailability:In stockNet price:€4.00
Description
The GC series of portable desktop chargers is designed to charge various types of batteries, including lead-acid, lithium-manganese (Li-MnO2), lithium-iron (LiFePO4) lead-acid gel, and others. The chargers have two stages of charging (constant voltage and constant current) and can monitor the battery capacity by detecting its voltage. The device can quickly charge the battery with constant current at low battery capacity, and after charging it switches to constant voltage charging with low charging current to extend battery life. The 30W models have a P1J plug, while the 120/160 / 220W models have an R7B (DIN 4P) connector or an optional AD1 connector (Anderson connector), and the GC330 model has a C4P connector.
Technical Specification
-
GC330: 261.1~326.4W DETAILS
Model Wyjście Zalecana pojemność Wydajność Wtyk Wymiary GC330A36 40.8V, 8A 20~65Ah 93.5% C4P 220x95x46mm GC330A48 54.4V, 6A 20~65Ah 93.5% C4P 220x95x46mm
