- EIB / KNX power supply with integrated choke
- Compact size with 4SU width(72mm)
- Safety extra low voltage(SELV)
- Suitable for TP1-256
- 180~264VAC input
- Protections: Short circuit / Overload(short-circuit-proof) / Over voltage
- Cooling by free air convection
- Isolation class I
- LED indicator for normal operation, bus reset and bus overload
- Monitoring of output voltage,output current,bus traffic load and device temperature
- Provide Wide variety of diagnostic and logic function
- Over Voltage category III
High price? Log in and buy cheaper
Place the order by 12:00, the package will be shipped on the same day
Free shipping from €300
Promocja cenowa na model HDR-15-5
KNX-40E-1280
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddKNX-40E-1280KNX power supply 38.4W 30V1.28AIn stockWarranty: €133.70€164.45Login to check your price KNX-40E-1280KNX power supply 38.4W 30V1.28AAvailability:In stockNet price:€133.70 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddKNX-40E-1280DKNX power supply 38.4W 30V1.28AIn stockWarranty: €179.30€220.54Login to check your price KNX-40E-1280DKNX power supply 38.4W 30V1.28AAvailability:In stockNet price:€179.30
Description
MEAN WELL,the leading standard power supply manufacturer,continues to promote the buiding automation technology for making a green and sustainable society.After the launch of KNX-20E-640,the new KNX power supply KNX-40E-1280(D) is proudly introduced.
The KNX Power Supply KNX-40E-1280(D) is a 1280mA power supply with high efficiency and a small footprint of only 4SU(72mm).The device has a KNX bus choke output and additional output for auxiliary power.The -30~+70°C wide temperature operating range can meet all kinds of applications. For troubleshooting,monitoring purpose, output voltage, output current, bus traffic, device temperature and other actual measurement values can be sent via KNX.LED indicators are used in case of normal operation,overload conditions and RESET operation.|t is perfectly suitable to power up any products labeled with the KNX trademark.
Available models:
- 30V: KNX-40E-640
Technical Specification
KNX-40E: 38.4WW DETAILS
| Model | Output | Ripple & noise | Efficiency | Dimension |
| KNX-40E-640 | 30V, 1,28A | 100mV | 86% | 72x90x57mm |
