P1J DC adapters
- 2 pole EURO plug , Class II power unit
- Medical safety approved (2 x MOPP) according to EN60601-1/-1-11
- Extremely low leakage current
- Energy efficiency Level VI and meet COC version 5( except 5~9V for Level V)
- -25~+60°C wide range working temperature
- Protections: Short circuit / Overload / Over voltage
- LED indicator for power on
High price? Log in and buy cheaper
Free shipping from €300
Promocja cenowa na model HDR-15-5
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E05-P1Jwall plug-in power supply EU 18W 5V 3AIn delivery Warranty: €13.90€17.10Login to check your price GSM18E05-P1Jwall plug-in power supply EU 18W 5V 3AAvailability: In deliveryNet price:€13.90 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E07-P1Jwall plug-in power supply EU 18W 7.5V 2AOut of stock Warranty: €13.90€17.10Login to check your price GSM18E07-P1Jwall plug-in power supply EU 18W 7.5V 2AAvailability: Out of stockNet price:€13.90 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E09-P1Jwall plug-in power supply EU 18W 9V 2AOut of stock Warranty: €13.90€17.10Login to check your price GSM18E09-P1Jwall plug-in power supply EU 18W 9V 2AAvailability: Out of stockNet price:€13.90 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E12-P1Jwall plug-in power supply EU 18W 12V 1.5AOut of stock Warranty: €13.90€17.10Login to check your price GSM18E12-P1Jwall plug-in power supply EU 18W 12V 1.5AAvailability: Out of stockNet price:€13.90 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E15-P1Jwall plug-in power supply EU 18W 15V 1.2AOut of stock Warranty: €13.90€17.10Login to check your price GSM18E15-P1Jwall plug-in power supply EU 18W 15V 1.2AAvailability: Out of stockNet price:€13.90 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E18-P1Jwall plug-in power supply EU 18W 18V 1AOut of stock Warranty: €13.90€17.10Login to check your price GSM18E18-P1Jwall plug-in power supply EU 18W 18V 1AAvailability: Out of stockNet price:€13.90 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E24-P1Jwall plug-in power supply EU 18W 24V 0.75AIn delivery Warranty: €13.90€17.10Login to check your price GSM18E24-P1Jwall plug-in power supply EU 18W 24V 0.75AAvailability: In deliveryNet price:€13.90 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddGSM18E48-P1Jwall plug-in power supply EU 18W 48V 0.375AOut of stock Warranty: €13.90€17.10Login to check your price GSM18E48-P1Jwall plug-in power supply EU 18W 48V 0.375AAvailability: Out of stockNet price:€13.90
Useful products
Description
GSM series is a highly reliable, wall-mounted style single-output green medical adaptor series. This product is equipped with a 2-pin (no FG) standard European power plug, adopting the input range from 80VAC to 264VAC. The entire series supplies different output voltages between 5VDC and 48VDC that can satisfy the demands for various kinds of miniature medical devices. The circuitry design meets the international medical standards (2 x MOPP), having an ultra low leakage current, fitting the medical devices in direct electrical contact with the patients.
With the extreme low no-load power consumption below, GSM series is compliant with EU ErP and meet Code of Conduct(CoC) Version 5; the supreme feature allows the adaptor to save the energy when it is either under the operating mode or the standby mode. The entire series utilizes the 94V-0 flame retardant plastic case, providing the double insulation that effectively prevents electrical shock. GSM series is approved with the international medical safety certificates.
Available models:
- 5V: GSM06E05-P1J, GSM18E05-P1J, GSM25E05-P1J, GSM36E05-P1J
- 6V: GSM06E06-P1J
- 7.5V: GSM06E07-P1J, GSM18E07-P1J, GSM25E07-P1J, GSM36E07-P1J
- 9V: GSM06E09-P1J, GSM18E09-P1J, GSM25E09-P1J, GSM36E09-P1J
- 12V: GSM06E12-P1J, GSM18E12-P1J, GSM25E12-P1J, GSM36E12-P1J
- 15V: GSM06E15-P1J, GSM18E15-P1J, GSM25E15-P1J, GSM36E15-P1J
- 18V: GSM06E18-P1J, GSM18E18-P1J, GSM25E18-P1J, GSM36E18-P1J
- 24V: GSM06E24-P1J, GSM18E24-P1J, GSM25E24-P1J, GSM36E24-P1J
- 48V: GSM18E48-P1J, GSM25E48-P1J, GSM36E48-P1J
Technical Specification
- GSM18E: 15~18W DETAILS
Model | Output | Tolerance | Ripple & noise | Efficiency | Plug | Dimension |
GSM18E05-P1J | 5V, 0~3A | +/-5% | 60mV | 80% | 2.1Øx5.5Øx11mm | 79x54x33mm |
GSM18E07-P1J | 7.5V, 0~2A | +/-5% | 80mV | 83% | 2.1Øx5.5Øx11mm | 79x54x33mm |
GSM18E09-P1J | 9V, 0~2A | +/-5% | 80mV | 84% | 2.1Øx5.5Øx11mm | 79x54x33mm |
GSM18E12-P1J | 12V, 0~1.5A | +/-3% | 120mV | 85% | 2.1Øx5.5Øx11mm | 79x54x33mm |
GSM18E15-P1J | 15V, 0~1.2A | +/-3% | 120mV | 85% | 2.1Øx5.5Øx11mm | 79x54x33mm |
GSM18E18-P1J | 18V, 0~1A | +/-3% | 150mV | 86% | 2.1Øx5.5Øx11mm | 79x54x33mm |
GSM18E24-P1J | 24V, 0~0.75A | +/-2% | 180mV | 87% | 2.1Øx5.5Øx11mm | 79x54x33mm |
GSM18E48-P1J | 48V, 0~0.375A | +/-2% | 240mV | 88% | 2.1Øx5.5Øx11mm | 79x54x33mm |
