Manufacturer: MEAN WELL
- wide input voltage range 8:1
- DIP housing 1"x1"
- cooling in open air circulation
- compliance with EN55032 - class A
- operating temperature -40~+90°C
- short-circuit strength 3kVDC
- efficiency up to 86%
- low costs, high reliability
- protection: short-circuit, overload, overvoltage
- remote on/off function
- 3 years warranty
Prices with discounts and exact stock levels are visible after logging in to the e-shop.
Product out of stock
Free shipping from €300
Promocja cenowa na model HDR-15-5
Product intended for professional use only
Description
The series of two-output converters for through-hole and surface mounting is intended for use in electronics. A wide range of input voltages, models with different powers and output voltages ensure great flexibility of applications. High quality, reliability, durability and long life are the basic advantages of MEAN WELL converters.
Technical Specification
- DI06W8: 2-output DC/DC converter 6W SPECIFICATION
| Model | Input | Output | Ripple&Noise | Dimensions |
| DI06W8-05 | 9~75VDC | +/-5VDC, 600mA | 100mV | 25.4x25.4x10.2mm |
| DI06W8-12 | 9~75VDC | +/-12VDC, 250mA | 100mV | 25.4x25.4x10.2mm |
| DI06W8-15 | 9~75VDC | +/-15VDC, 200mA | 100mV | 25.4x25.4x10.2mm |
