Manufacturer: MEAN WELL
- supply voltage: 180-528VAC; 254-747VDC
- hermetic metal housing in accordance with the IP67 / IP65 standard
- built-in active PFC function
- constant current at the output
- short-circuit, over-voltage and thermal protection
- regulation of the output voltage with a potentiometer in version A
- regulation of the output current with a potentiometer
- 3in1 dimming function in B version models (0 ~ 10VDC, PWM, resistor)
- cooling with open air circulation
- working temperature -40 ~ + 70 ° C
- efficiency up to 93%
- compliance with a number of standards and certificates
- 5-year warranty
Discounted prices and exact stock levels are visible after logging in to the e-shop.
Price from €171.80 Net price
High price? Log in and buy cheaper
Product out of stock
Free shipping from €300
Promocja cenowa na model HDR-15-5
HVGC-480
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddHVGC-480-L-ABLED driver 480W 137~343V 1.4~1.75AOut of stock Warranty: €171.80€211.31Login to check your price HVGC-480-L-ABLED driver 480W 137~343V 1.4~1.75AAvailability: Out of stockNet price:€171.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddHVGC-480-M-ABLED driver 480W 92~228.5V 2.1~2.625AOut of stock Warranty: €171.80€211.31Login to check your price HVGC-480-M-ABLED driver 480W 92~228.5V 2.1~2.625AAvailability: Out of stockNet price:€171.80 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddHVGC-480-H-ABLED driver 480W 68~171.5V 2.8~3.5AOut of stock Warranty: €171.80€211.31Login to check your price HVGC-480-H-ABLED driver 480W 68~171.5V 2.8~3.5AAvailability: Out of stockNet price:€171.80
Description
The HVGC series current power supplies have an extended input voltage range, up to 480VAC (single-phase powered). They are available in versions, ie A, B and AB (with cable outlet) or version D (with a built-in dimming timer - optional). The models have a 3 in 1 dimming function. The whole series has a built-in active PFC function. They are designed to power a wide range of devices, including lighting and decorative LED systems, including individual LEDs, strips, modules, panels, halogen LED bulbs, etc.
Technical Specification
- HVGC-480 LED power supplies with high input voltage 480W SPECIFICATION
| Model | Output | Tolerance | Ripple&Noise | Efficiency | Cable length | Dimensions |
| HVGC-480-L | 137~343V, 1400mA | +/-5% | +/-5% Io | 93.5% | 300mm | 262x125x43.8mm |
| HVGC-480-M | 92~228V, 2100mA | +/-5% | +/-5% Io | 93% | 300mm | 262x125x43.8mm |
| HVGC-480-H | 68~171V, 2800mA | +/-5% | +/-5% Io | 93% | 300mm | 262x125x43.8mm |
