POC-764VR
Intel Core i3-N305 Fanless Surveillance System with 4x PoE+ and 2x 2.5” SSD Supporting RAID 0/1
- Intel Alder Lake Core i3-N305 processor 15W with 8 E-Cores
- Up to 16GB DDR5-4800 SODIMM
- 4x GbE ports PoE+ and 1x 2.5GbE LAN Port
- 4x USB 3.2 Gen2 ports with screw-lock
- 1x M.2 2280 M key socket & 2x MiniPCIe socket with micro SIM card
- 2x 2.5” SSD support RAID 0/1/JBOD
- -10 °C to 70 °C temperature operation
- 8-35V DC input with built-in ignition power control
Free shipping from €300
Promocja cenowa na model HDR-15-5
Product intended for professional use only
POC-764VR
Description
The POC-764VR is Neousys' new ultra-compact surveillance computer platform. Built on the foundation of the POC-700 series, it offers advanced RAID storage and enhanced networking capabilities, making it ideal for surveillance, security, and smart city applications. The system ensures data redundancy, reliability, and seamless connectivity in critical environments.
Featuring four Gigabit PoE+ ports and an ignition function, the POC-764VR can connect up to four IP cameras for both mobile and stationary surveillance applications. Its RJ45 locking mechanism guarantees reliable Ethernet connectivity in dynamic environments. For video recording, it comes with a built-in hardware RAID controller that supports dual 2.5" HDD/SSDs in RAID 0/1 configuration, enhancing data redundancy or providing extensive storage capacity. Additionally, a 2.5 GbE port offers flexible data exchange with backbone infrastructure, while two mini-PCIe sockets support wireless WiFi, LTE/5G, or CAN bus devices.
The POC-764VR is powered by an Intel Alder Lake Core i3-N305 8-core/8-thread processor with 32EUs UHD Graphics, delivering not only significant computing performance but also enabling real-time AI inference through Intel OpenVINO. Its compact size, PoE+ capabilities, and RAID storage make the POC-764VR an ideal platform for surveillance, public safety monitoring, and asset management applications.
Technical Specification
| POC-764VR | |
| CPU | Intel Alder Lake Core i3-N305 |
| Memory | up to 16GB SODDR5 |
| DisplayPort | 1 |
| HDMI |
1 |
| Audio | - |
| Gigabit Ethernet | 5 (PoE+ on port #1-4) |
| Slot 2,5" HDD | 2 (supports RAID 0/1) |
| Slot mSATA | - |
| Slot M.2 | 1x M.2 2280 M key socket for NVMe SSD storage |
| Slot miniPCIe | 2x full-size with internal micro SIM socket |
| USB 3.2 | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| Isolated DIO | 4x isolated DI and 4x isolated DO |
| TPM | Supports dTPM 2.0 |
| Working temperature | -10°C ~ +70°C |
