ABC4011 - EtherNet/IP adapter - Modbus TCP server
Price from €948.00 Net price
If placed an order by 3 p.m., the package will be shipped the same day In stock
Description
Technical Specification
- Specyfikacja techniczna
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 24 VDC (?10%) |
| Temperature: | 0-65°C |
| Current Consump: | max 300 mA |
| Baud Rate: | 1 Mbit/s |
| I/O Input: | Default 20 bytes, max 512 bytes (max 64 bytes as Modbus Plus Global Data) |
| I/O Output: | Default 20 bytes, max 512 bytes (max 64 bytes as Modbus Plus Global Data) |
| Mech Rating: | IP20/Nema1 |
| Config Method: | Windows Hyper Terminal |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connector: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| Modbus Plus address: | Node-ID and Source-ID 1-64 |
| ModbusPlus connector: | D-sub 9-pin female |
| Price Group: | C |
| Order Code: | AB7623 |
