AB7651
Anybus X-gateway PROFINET-IO Slave PROFINET-IO Slave
Price from €948.00 Net price
High price? Log in and buy cheaper
Product out of stock
Free shipping from €300
Promocja cenowa na model HDR-15-5
Product intended for professional use onlyModels
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAB7651Profinet IO Slave - Profinet IO SlaveOut of stock Warranty: €948.00€1,166.04Login to check your price AB7651Profinet IO Slave - Profinet IO SlaveAvailability: Out of stockNet price:€948.00
Technical Specification
- Specyfikacja techniczna
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 24 VDC (?10%) |
| Temperature: | 0-65°C°C |
| Current Consump: | max 300 mA |
| Baud Rate: | 100 Mbit/s |
| I/O Input: | Default 20 bytes, max 512 bytes |
| I/O Output: | Default 20 bytes, max 512 bytes |
| Mech Rating: | IP20/Nema1 |
| Config Method: | Windows Hyper Terminal, GSD file for Profinet |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connect: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| Profinet connectors:: | RJ45 |
| Profinet IP-address: | Any valid IP-addresses |
| Profinet config.: | Configured by any Profinet master using the supplied GSD file |
| Price Group: | A |
| Order Code: | AB7651 |
Download
