AB7842
AB7842 Ethernetip Slave Lonworks
Product out of stock
Free shipping from €300
Promocja cenowa na model HDR-15-5
Product intended for professional use onlyTechnical Specification
- Specyfikacja techniczna
| Size: | 126 mm x 110 mm x 42 mm |
| Power Supply: | 24 VDC (?10%) |
| Temperature: | 0-65°C |
| Current Consump: | max 300 mA |
| I/O Input: | Default 20 bytes, max 512 bytes (256 network variables on LonWorks) |
| I/O Output: | Default 20 bytes, max 512 bytes (256 network variables on LonWorks) |
| Mech Rating: | IP20/Nema1 |
| Config Method: | Windows Hyper Terminal |
| UL certification: | E203225, Listed 67AM, UL-1604 Class 1, Div 2, GP A, B, C, D, Temp Code T4 |
| ATEX certification: | ATEX 135419, II 3 G, EEx nL IIC T4, DEMKO 03 |
| Power supply connector: | 2-pole 5.08 mm Phoenix pluggable screw connector |
| Ethernet/IP baudrate: | 10/100 Mbit/s autodetect |
| Ethernet connector: | RJ45 |
| Ethernet/IP address: | Any valid IP-address |
| Ethernet/IP config.: | Configured by EtherNet/IP Scanner via EDS file (provided by HMS) |
| LonWorks baudrate: | 78 kbit/s |
| LonWorks Connector: | 5-pole 5.08 mm Phoenix pluggable screw connector |
| Price Group: | C |
| LonWorks config.: | Order code: 018640 - (LW Tool ABX for LonWorks interface variable configuration) |
| Order Code: | AB7842 |
Download
