Industrial stepper motor
Price from €169.00 Net price
If placed an order by 3 p.m., the package will be shipped the same day In stock
Price from €142.00 Net price
High price? Log in and buy cheaper
Product out of stock
Free shipping from €300
Promocja cenowa na model HDR-15-5
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddA-CSD 04A-CSD stepper drive (24/48V - 4,4A), step&dir control, open frame, AMP connectorOut of stock Warranty: €142.00€174.66Login to check your price A-CSD 04A-CSD stepper drive (24/48V - 4,4A), step&dir control, open frame, AMP connectorAvailability: Out of stockNet price:€142.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddA-CSD 04.VA-CSD stepper drive (24/48V - 4,4A), step&dir control, open frame, zaciski śruboweOut of stock Warranty: €145.00€178.35Login to check your price A-CSD 04.VA-CSD stepper drive (24/48V - 4,4A), step&dir control, open frame, zaciski śruboweAvailability: Out of stockNet price:€145.00
Useful products
Industrial stepper motor
Price from €44.00 Net price
If placed an order by 3 p.m., the package will be shipped the same day In stock
Description
New series of bipolar microstep stepping motor drives, specifically developed for applications sensitive to acoustic noise and vibration. Significant evolution of the CSD series, preserving backward mechanical, electrical and applicative compatibility.
Target: advanced applications requiring high precision, smoothness of movement and low acoustic noise.
Highlights:
- Full digital microstepping drive.
- Adaptive microstepping up to 3.200 step/rev.
- Intelligent management of the current profile that achieves good results in terms of smoothness of movement, low noise and vibration control.
- A highly sophisticated control system, preserving anyhow the traditional ease of use of R.T.A. drives.
- UL Recognized
Technical Specification
| Voltage | 24-48 VDC |
| Current (A) | 2,6 - 4,4 |
| Microstepping (step/rev) | 400, 800, 1600, 3200 |
| Type | Step&Direction Advanced |
| Dimensions (mm) | 92 x 85 x 23 |
| Connector | AMP/Screw-type |
| Functions |
Automatic current reduction at motor standstill. Management of the current profile setting by means of a dip-switch. Electronic damping facility for further acoustic noise and mechanic vibrations reduction. |
| Protections |
Protection against under-voltage and over-voltage. |
| Warranty |
24 months |
