ICR-2436

Advantech ICR-2436 - Cellular Router, Cat18, Private LTE, 2x ETH

Manufacturer: Advantech
Manufacturer: Advantech
  • Global LTE coverage with 3G fallback
  • Full support for QCI-70 Quality of Service (3GPP Release 12)
  • Private LTE frequency bands 42, 43, 48 (CBRS)
  • 2× SIM for redundancy
  • 2× Ethernet 10/100 Mbps
  • 1× RS232, 1× RS485
  • 1× DI, 1× DO
  • Wall and DIN mount options
  • Linux based OS & SW customization
Price from €588.00 Net price

High price? Log in and buy cheaper

Product out of stock

Free shipping from €500

See 1 model

Promocja cenowa na model HDR-15-5

Models

  • ModelAvailabilityWarrantyWishlist
    Your Price
    Your Price
    ICR-2436
    Cellular Router, Cat18, Private LTE, 2x ETH
    Out of stock Warranty: 36 months
    €588.00
    €723.24
    Login to check your price

Accessories

  • ModelAvailabilityWarrantyWishlist
    Your Price
    Your Price
    BB-DIN-ICR32
    DIN Clip - ICR-3200 Series
    Out of stock Warranty: 24 months
    €8.00
    €9.84
    Login to check your price
  • ModelAvailabilityWarrantyWishlist
    Your Price
    Your Price
    DIN rail power supply 15W 24V 0.63A
    In stock
    Warranty: 36 months
    €13.00
    €15.99
    Login to check your price
    160 pieces in box
  • ModelAvailabilityWarrantyWishlist
    Your Price
    Your Price
    RPS-ICR2-EU
    Power Supply, ICR2, 12V/1A, 6-pin, EU plug
    In stock
    Warranty: 24 months
    €12.00
    €14.76
    Login to check your price

Description

Industrial cellular router ICR-2436 is designed for communication in both public and private LTE networks (frequency spectrum 3500-3700 MHz - B42, B43, B48-CBRS). Private LTE provides complete control and guaranteed coverage for companies operating mission critical industrial applications. The high speed LTE connectivity is ideal for enterprise applications such as smart factory and smart city focusing on Industry 4.0.


The router is equipped with two independently configurable Ethernet ports (LAN or WAN), 1× serial port RS232, 1× RS485, and with digital I/O connectivity (1× DI, 1× DO). The router supports VPN tunnel creation using various protocols to ensure safe communications. The router provides diagnostic functions which include automatic monitoring of the wireless and wired connections, automatic restart in case of connection losses, and a hardware watchdog that monitors the router status.


Router is based on ICR-OS operation system. Open Linux platform enable wide possibilities of programming customer SW applications in Python, C/C++. Router supports uploading of RouterApps (User modules) that would extend standard firmware functionalities. Existing app library ready for free download by customer contains already developed software apps to enhance specific router functionality including industrial protocol conversions, support of IoT platforms such as MS Azure, Cumulocity, ThingWorx and a lot more.

Technical Specification

  • Wi-FiNo
    Port RS-232Yes
    Port RS-485Yes
    Rodzaj obudowyMetal
    AkcesoriaNo accessories
