ARK-1250L
Intel® 11th gen Core™ i processor with Triple LAN/ Quadruple COM Din-Rail Fanless Box PC
Manufacturer: Advantech
Manufacturer: Advantech
- Intel 11th Gen. Core i5/i3
- DIN-Rail system with essential I/O ports on front-side bezel
- 3 x Intel GbE, 4x RS-232/422/485
- 3 x USB 3.2 and 3 x USB 2.0, dual independent displays with one 4K HDMI and one VGA
- 3 Expansion: M.2 E-Key 2230, M.2 B-Key 2280, 1 x Full-size mSATA share with mPCIe slot
- mSATA and 1 x 2.5" SATA storage device
- 12V ~ 24V wide range power input
- -40 ~ 60 °C extended operating temperature
- WISE-DeviceOn supported for quick AI deployment at scale
In stock
Place the order by 12:00, the package will be shipped on the same day
Free shipping from €300
Promocja cenowa na model HDR-15-5
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddARK-1250L-S5A1Intel Core i5-1145G7E HDMI+VGA+3*GbE+4*COMOut of stock Warranty: €1,732.00€2,130.36Login to check your price ARK-1250L-S5A1Intel Core i5-1145G7E HDMI+VGA+3*GbE+4*COMAvailability: Out of stockNet price:€1,732.00 -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddARK-1250L-U2A1Intel Core i3-1115G4E HDMI+VGA+3*GbE+4*COMIn stockWarranty: €1,276.00€1,569.48Login to check your price ARK-1250L-U2A1Intel Core i3-1115G4E HDMI+VGA+3*GbE+4*COMAvailability:In stockNet price:€1,276.00
Description
Intel® 11th gen Core™ i processor with Triple LAN/ Quadruple COM Din-Rail Fanless Box PC
Technical Specification
| Part Number | ARK-1250L-U2A1 | ARK-1250L-S5A1 |
| Processor | ||
| CPU | Intel Core i3-1115G4E | Intel Core i5-1145G7E |
| Frequency | 2.2GHz | 1.5GHz |
| Core Number | 2 | 4 |
| BIOS | AMI EFI 256Mbit | AMI EFI 256Mbit |
| Memory | ||
| Technology | DDR4 3200MHz | DDR4 3200MHz |
| Max Capacity | 64GB | 64GB |
| Socket | 2x 260-pin SO -DIMM | 2x 260-pin SO -DIMM |
| Graphics | ||
| HDMI | 4096x 2160@60Hz | 4096x 2160@60Hz |
| VGA | 1920x1200@60Hz | 1920x1200@60Hz |
| Dual Display | Yes ,VGA +HDMI | Yes ,VGA +HDMI |
| Ethernet | ||
| LAN1 | 10/100/1000/2500Mbps Intel 1225GbE ,support Wake On LAN | 10/100/1000/2500Mbps Intel 1225GbE ,support Wake On LAN |
| LAN2 | 10/100/1000Mbps Intel i219GbE ,support Wake On LAN | 10/100/1000Mbps Intel I219GbE ,support Wake On LAN |
| LAN3 | 10/100/1000/2500Mbps Intel 1225GbE ,support Wake On LAN | 10/100/1000/2500Mbps Intel i225 GbE ,support Wake On LAN |
| Audio | ||
| Interface | Realtek ALC888S ,High Definition Audio ,Line -out ,Mic -in | Realtek ALC888S ,High Definition Audio ,Line -out ,Mic -in |
| I/O Interface | ||
| Serial Port | 4x RS -232/422/485port with auto flow control | 4x RS -232/422/485port with auto flow control |
| GPIO | 8bit GPIO | 8bit GPIO |
| USB | 2x USB3.2 ,2x USB2.0 ,1x internal USB2.0 for security dongle | 2x USB3.2 ,2x USB2.0 ,1x internal USB2.0 for security dongle |
| Optional I /O | 1x CANBus 2.0(DB9 connector ) | 1x CANBUS 2.0(DB9 connector ) |
| Expansion | ||
| Mini PCI Express | 1x Full -size | 1x Full -size |
| M.2 | 1x M2 .2230E key and 1x M.2 2280B key with nano SIM holder | 1x M2 .2230E key and 1x M.2 2280B key with nano SIM holder |
| Storage | ||
| 2.5"HDD /SSD | 1x 2.5"SATAIII Drive bay (compatible with 15mmheight ) | 1x 2.5"SATAIII Drive bay (compatible with 15mmheight ) |
| mSATA | 1x Full -size (support either mSATA or miniPCle ) | 1x Full -size (support either mSATA or miniPCle ) |
| Other | ||
| Watchdog Timer | 255levels timer interval ,setup by software | 255levels timer interval ,setup by software |
| Software Support | ||
| Microsoft Windows | Windows 10Enterprice | Windows 10Enterprice |
| Linux | Support by project | Support by project |
| Operating System | ||
| Ubuntu | V | V |
| Power Requirement | ||
| Power Type | AT /ATX | AT /ATX |
| Input Voltage | 12-24VDC | 12-24VDC |
| Power Adapter | AC to DC 19V/4.74A90W(Default) | AC to DC 19V/4.74A90W(Default) |
| Mechanical | ||
| Construction | Aluminum housing | Aluminum housing |
| Mounting | DIN -rail /Wall Mount | DIN -rail /Wall Mount |
| Dimensions | 60x 173x 141mm (2.36x 6.73x 5.55in ) | 60x 173x 141mm (2.36x 6.73x 5.55in ) |
| Weight | 1.5kg (3.3lb) | 1.5kg (3.3lb) |
| Environment | ||
| Temperature (Operating ) | -40-60°C | -40-60°C |
| Temperature (Storage ) | -40-85°C (-40-185°F ) | -40~85°C (-40~185°F ) |
| Relative Humidity | 95%40°C (non -condensing ) | 95%@40°C (non -condensing ) |
| Vibration during Operation | With SSD :3Grms ,IEC 60068-2-64,random ,5-500Hz ,1hr /axis | With SSD :3Grms ,IEC 60068-2-64,random ,5-500Hz ,1hr /axis |
| Shock Protection | With SSD /mSATA :30G | With SSD /mSATA :30G |
| Certifications | ||
| Safety | UL ,CB ,CCC | UL ,CB ,CCC |
| EMC | CE ,FCC class B | CE ,FCC class B |
| Others | ||
| TPM | TPM 2.0(by optional AMO -1029) | TPM 2.0(by optional AMO -1029) |
| Power Consumption | ||
| Typical | 18W | 19.8W |
| Maximum | 30.6W | 35.1W |
