In IIoT and Industry 4.0 era, more and more customers need data to be visualized to benefit process management and decision making. The FPM-100W series is a semi-industrialgrade monitor which provides vivid images and intuitive multi-touch functionalities. Along with its slim and compact design, FPM-100W series is suitable to be placed everywherethat both information display and human interactions are required to increase the production efficiency.
General |
|
Certification |
BSMI, CCC, CE, FCC Class A, UL |
Dimensions |
382 x 241.3 x 43.8 mm |
Enclosure |
Front: ABS |
Mount |
VESA |
OS |
Windows XP, Vista,7, 8,10,XPe and Linux |
Power Input |
External 36 W power adapter, with AC 100 V ~ 240 Vinput and DC +12 V @ 3 A output (included) |
Power Consumption |
15W +20% |
Video Port |
HDMI, DP |
Weight |
1,5 kg |
Display |
|
Type |
Full HD |
Size |
15,6'' |
Resolution |
1920 x 1080 |
Max. Color |
262K |
Viewing Angle |
170°/170° |
Luminance |
220 cd/m2 |
Backlight Life |
15,000 h |
Contrast |
800:1 |
Touchscreen |
|
Type |
Projected Capacitive Touch (P-CAP) |
Interface |
USB |
Light Transmission |
Above 85% |
Environment |
|
Operating Temperature |
0 ~ 50 °C |
Storage Temperature |
-10 ~ 60 °C |
Humidity |
10 ~ 90% RH @ 40 °C, non-condensing |
Vibration |
1 Grms (5 ~ 500 Hz) (Operating, Random) |
